Between Greenland and Spitsbergen, scientists have found the scours on the sea bed left behind by gigantic icebergs - about three times the height of the Empire State Building. The five lineaments, at a depth of 1,200 meters, are the lowest-lying iceberg scours yet to be found on the Arctic sea floor, and provide insight into the dynamics and the extent of last Ice Age and the Arctic ice sheet thousands of years ago.

"Whenever icebergs run aground, they leave scours on the seabed. Depending on their depth and location, those markings may continue to exist over long periods of time," explained Jan Erik Arndt,  Alfred Wegener Institute, Helmholtz Centre for Polar and Marine Research (AWI) bathymetrician and lead author of a new paper on the subject.

He and three colleagues discovered the scours on on the Hovgaard Ridge. The Hovgaard Ridge is a plateau in the deep Arctic Sea, around 400 kilometers off of Greenland's eastern coast. Found at a depth of 1,200 meters the five lineaments are the deepest iceberg scours found to date in the Arctic. The scours are as much as four kilometers long and 15 meters in depth.


A rare blue iceberg in Antarctic waters. Photo: J. Wassmuth, Alfred-Wegener-Institut

"Such scours are a window into the past. Thanks to these iceberg scours we now know that a few very large, but also many smaller icebergs, passed across the Hovgaard Ridge," the scientist said.

The discovery of the scours on Hovgaard Ridge was fortuitous and by no means the result of a defined search. Jan Erik Arndt and his colleagues discovered the lineaments when examining bathymetric data from the year 1990. The data were collected by the research ship Polarstern while preparing cartography for the Fram Strait.

"When we examined the data once again and in greater detail, we became aware of the scours. Given their depth, it quickly became clear that we had found something very interesting," says Arndt.

The scientists today work with better hardware and software than what was available in the 1990s. This new technology allows closer scrutiny of the old data. That is why the scours have surfaced on the scientists' monitors only now, 24 years after the data were collected.

The scientists can, however, only roughly bracket the period within which the icebergs scoured the ridge crest. It is clear, however, that it must have taken place within the past 800,000 years. Since sea level during the glacial period was a good 120 meters lower than today, the icebergs reached to a depth of at least 1,080 meters below sea level. Since about a tenth of an iceberg will, as a rule, be exposed, AWI scientists estimate the height of the iceberg to be roughly 1,200 meters – about three times the height of the Empire State Building.

"To calve such megascale icebergs, the edge of the ice sheet covering the Arctic Ocean must have been at least 1,200 meters thick," Arndt notes.


Bathymetric overview map of Fram Strait. Credit: AWI

Today scientists search in vain for such megascale icebergs. "We currently find the largest icebergs in the Antarctic. The very biggest reach only 700 meters below the water's surface," noted the bathymetrician. One remaining riddle is the birthplace of the massive icebergs that scraped Hovgaard Ridge. The AWI scientists suggest that two areas off the northern coast of Russia are the most likely sites.

The researchers are interested in these scours not only because of the size of the icebergs. The traces have caused a flare up in the old discussion about how fresh water was transported from the Arctic and into the Atlantic Ocean. In the past, some scientists assumed that thick sea ice was primarily responsible for fresh water export from the Arctic. The newly discovered scours, however, support another hypothesis: Large icebergs drifted southward through the Fram Strait, carrying large volumes of frozen fresh water into the North Atlantic.

Numerous studies make the increased imports of fresh water responsible for the end of North Atlantic deep water formation at the close of the last ice age. As a consequence, the Gulf Stream ebbed, making for drastic cooling in Europe. Since the currents in the Atlantic are an important engine, driving the global system of circulation, the effects were perceived around the world.

"The fact that icebergs of this order of magnitude were driven from the Arctic is clear evidence that icebergs played a more serious role in freshwater imports than what we had previously assumed," Arndt concludes.


Jan Erik Arndt, Frank Niessen, Wilfried Jokat, Boris Dorschel: Deep water paleo-iceberg scouring on top of Hovgaard Ridge–Arctic Ocean, Geophysical Research Letters, DOI: 10.1002/2014GL060267. Source: Alfred Wegener Institute, Helmholtz Centre for Polar and Marine Research
