The astronomer Giovanni Schiaparelli first described them as 'canali' in the 19th century. A conspicuous net-like system of deep gorges known as the Noctis Labyrinthus is clearly visible on Mars' equatorial region.
The gorge system, in turn, leads into another massive canyon, the Valles Marineris, which is 4,000 km long, 200 km wide and 7 km deep. Both of these together would span the US completely from east to west.
These gorges resemble terrestrial canyons formed by water so most researchers assumed that immense flows of water must have carved the Noctis Labyrinthus and the Valles Marineris into the surface of Mars. Or perhaps tectonic activity had created the largest rift valley on a planet in our solar system.
No discernible evidence of erosion by water
Neither is correct, believes Giovanni Leone, a specialist in planetary volcanism in the research group of ETH Zurich. Only lava flows would have had the force and mass required to carve these gigantic gorges into the surface of Mars.
It's not a new idea, researchers have been saying it for almost 40 years, but it has failed to gain any traction. "I expect a spirited debate," Leone says. "But my evidence is strong."
In recent years, Leone has examined intensively the structure of these canyons and their outlets into the Ares Vallis and the Chryse Planitia, a massive plain on Mars' low northern latitude. He examined thousands of high-resolution surface images taken by numerous Mars probes, including the latest from the Mars Reconnaissance Orbiter, and which are available on the image databases of the US Geological Survey.
His conclusion is unequivocal: "Everything that I observed on those images were structures of lava flows as we know them on Earth," he emphasizes. "The typical indicators of erosion by water were not visible on any of them."
Leone knows he cannot eliminate water as a final formative force. Evidence of water, such as salt deposits in locations where water evaporated from the ground or signs of erosion on the alluvial fans of the landslides, exist. "One must therefore ask oneself seriously how Valles Marineris could have been created by water if one can not find any massive and widespread evidence of it."
He also wonders where the massive amounts of water that would be required to form such canyons might have originated.
Source region of lava flows identified
The explanatory model presented by Leone in his study illustrates the formation history from the source to the outlet of the gorge system. He identifies the volcanic region of Tharsis as the source region of the lava flows and from there initial lava tubes stretched to the edge of the Noctis Labyrinthus. When the pressure from an eruption subsided, some of the tube ceilings collapsed, leading to the formation of a chain of almost circular holes, the 'pit chains'.
When lava flowed again through the tubes, the ceilings collapsed entirely, forming deep V-shaped troughs. Due to the melting of ground and rim material, and through mechanical erosion, the mass of lava carved an ever-deeper and broader bed to form canyons. The destabilized rims then slipped and subsequent lava flows carried away the debris from the landslides or covered it. "The more lava that flowed, the wider the canyon became," says Leone.
Leone supported his explanatory model with height measurements from various Mars probes. The valleys of the Noctis Labyrinthus manifest the typical V-shape of 'young' lava valleys where the tube ceilings have completely collapsed. The upper rims of these valleys, however, have the same height. If tectonic forces had been at work, they would not be on the same level, he says. The notion of water as the formative force, in turn, is undermined by the fact that it would have taken tens of millions of cubic kilometers of water to carve such deep gorges and canyons.
Practically all the atmospheric water of all the ages of Mars should have been concentrated only on Labyrinthus Noctis. Moreover, the atmosphere on Mars is too thin and the temperatures too cold. Water that came to the surface wouldn't stay liquid, he notes: "How could a river of sufficient force and size even form?"
That Would Make Life less likely
Leone's study could have far-reaching consequences. "If we suppose that lava formed the Noctis Labyrinthus and the Valles Marineris, then there has always been much less water on Mars than the research community has believed to date," he says.
Mars received very little rain in the past and it would not have been sufficient to erode such deep and large gorges. He adds that the shallow ocean north of the equator was probably much smaller than imagined – or hoped for; it would have existed only around the North Pole. The likelihood that life existed, or indeed still exists, on Mars is accordingly much lower.
Leone can imagine that the lava tubes still in existence are possible habitats for living organisms and unsurprisingly advocates mobilizing a mission to explore the lava tubes by sending a rover through a hole in the ceiling of a tube and search for evidence of life. "Suitable locations could be determined using my data."
It will take time to find out if anyone else is convinced.
