It is one of the few nebulas visible to the naked eye and is a popular target for amateur astronomers.
Images from Herschel’s far-infrared instrument and two of Spitzer’s instruments working at shorter wavelengths give us a more detailed picture of stars growing in the heart of one of the most famous objects in the night sky. The nebula contains the nearest site of massive star formation, with intense ultraviolet light from hot young stars causing gas and dust in the region to glow. Inside that dust – hidden at visible wavelengths – is a host of even younger stars, still growing in their earliest phase of evolution.
This view of the Orion Nebula shows embryonic stars within extensive gas and dust clouds. They combined far-infrared observations from the Herschel Space Observatory and mid-infrared observations from NASA's Spitzer Space Telescope. Data from the PACS instrument on Herschel at wavelengths of 70 and 160 microns (a micron is a millionth of a meter) are shown as green and red, respectively, and reveal emission from the disks and envelopes of the very youngest protostars. Two Spitzer instruments, IRAC and MIPS, were used to obtain images of the same region at 8 and 24 microns, which are combined here as blue. These wavelengths show emission from the hotter regions of discs around somewhat older stars. The region shown covers roughly 25x25 arcminutes on the sky or 3x3 parsecs at the distance to Orion. Credits: ESA/PACS/NASA/JPL-Caltech/IRAM
This new combined far- and mid-infrared image cuts through the obscuring dust and reveals these embryonic stars. A star forms when a dense cloud of gas and dust coalesces and then collapses under its own gravity, creating a central warm protostar surrounded by a swirling disc and a larger envelope. Much of this material will spiral in and collect on to the star over hundreds of thousands of years, before nuclear fusion is triggered at the core and it becomes a fully-fledged star. Some of the remnant gas and dust in the disc may go on to form a planetary system – as happened with our Solar System.
A team of astronomers led by Nicolas Billot of the Institut de Radioastronomie Millimétrique, in Granada, Spain used Herschel to image the Orion Nebula region once a week for six weeks in the late winter and spring last year. Herchel’s PACS Photodetector Array Camera and Spectrometer detected cold dust particles in discs around the youngest protostars at far-infrared wavelengths. This was combined with archival Spitzer images taken at shorter, mid-infrared wavelengths, which show older, hotter objects.
Astronomers were able to see the brightness of the young objects varying by more than 20% over those weeks - the accretion process should take years or even centuries. They now have to explain why this is happening.
One possibility is that lumpy filaments of gas are funnelling from the outer disc towards central regions near the star, temporarily warming the inner disc and leading it to brighten. Another scenario is that cold material is piling up at the inner edge and casting shadows on the outer disc, causing it to darken temporarily. In either case, it is clear that the gestation of baby stars is anything but a smooth, uniform process.
“Yet again, Herschel observations surprise us and provide more interesting insights in to what happens during the very earliest phases of stars and planet formation,” comments Göran Pilbratt, ESA’s Herschel Project Scientist. It is only through the unprecedented far-infrared sensitivity and resolution of the Herschel space observatory, combined with the shorter-wavelength data from Spitzer, that astronomers are able to witness and fully discover the physical processes of star birth.
