A set of enigmatic quasar ghosts mark the graves of these objects that flickered to life and then faded.

8 unusual looped structures orbit their host galaxies and glow in a bright and eerie goblin-green hue. The ethereal wisps in these images were illuminated, perhaps briefly, by a blast of radiation from a quasar - a very luminous and compact region that surrounds a supermassive black hole at the center of a galaxy - and Hubble was there to catch it.

The first object of this type was found in 2007 by Dutch schoolteacher Hanny van Arkel participating in the Galaxy Zoo project, which catalogs the Sloan Digital Sky Survey (SDSS). The bizarre feature was dubbed Hanny's Voorwerp (Dutch for Hanny's object).


CLICK FOR LARGER SIZE. In each of these eight images a quasar beam has caused once-invisible filaments in deep space to glow through a process called photoionisation. Oxygen, helium, nitrogen, sulphur and neon in the filaments absorb light from the quasar and slowly re-emit it over many thousands of years. Their unmistakable emerald hue is caused by ionised oxygen, which glows green. The Hubble team found a total of twenty galaxies that had gas ionised by quasars; those featured here are (from left to right on top row) the Teacup (more formally known as 2MASX J14302986+1339117), NGC 5972, 2MASX J15100402+0740370 and UGC 7342, and (from left to right on bottom row) NGC 5252, Mrk 1498, UGC 11185 and 2MASX J22014163+1151237. Credit:NASA, ESA, Galaxy Zoo Team and W. Keel (University of Alabama, USA.

Galactic material falls inwards towards the central black hole, growing hotter and hotter, forming a bright and brilliant quasar with powerful jets of particles and energy beaming above and below the disc of infalling matter.

In each of these eight images a quasar beam has caused once-invisible filaments in deep space to glow through a process called photoionization. Oxygen, helium, nitrogen, sulfur and neon in the filaments absorb light from the quasar and slowly re-emit it over many thousands of years. Their unmistakable emerald hue is caused by ionized oxygen, which glows green.

These ghostly structures are so far from the galaxy's heart that it would have taken light from the quasar tens of thousands of years to reach them and light them up. So, although the quasars themselves have turned off, the green clouds will continue to glow for much longer before they too fade.

Not only are the green filaments far from the centers of their host galaxies, they are also immense in size, spanning tens of thousands of light-years. They are thought to be long tails of gas formed during a violent past merger (between galaxies) -- this event would have caused strong gravitational forces that would rip apart the galactic participants.

Despite their turbulent past, these ghostly filaments are now leisurely orbiting within or around their new host galaxies. These Hubble images show bright, braided and knotted streams of gas, in some cases connected to twisted lanes of dark dust.

Galactic mergers do not just alter the forms of the previously serene galaxies involved; they also trigger extreme cosmic phenomena. Such a merger could also have caused the birth of a quasar, by pouring material into the galaxies' supermassive black holes.

These objects were found in a spin-off of the Galaxy Zoo project, in which about 200 volunteers examined over 16,000 galaxy images in the SDSS to identify the best candidates for clouds similar to Hanny's Voorwerp. A team of researchers analyzed these and found a total of 20 galaxies that had gas ionized by quasars.

Preprint: William C. Keel, W. Peter Maksym, Vardha N. Bennert, Chris J. Lintott, S. Drew Chojnowski, Alexei Moiseev, Aleksandrina Smirnova, Kevin Schawinski, C. Megan Urry, Daniel A. Evans, Anna Pancoast, Bryan Scott, Charles Showley, Kelsi Flatland HST Imaging of Fading AGN Candidates I: Host-Galaxy Properties and Origin of the Extended Gas arXiv:1408.5159. Upcoming in the Astronomical Journal.
