Backboned animals, at least the ones with jaws, have four fins or limbs, one pair in front and one pair behind.

Thanks to that random prankster known as evolution, these have been modified into a marvelous variety of fins, legs, arms, flippers, and wings. But how did our earliest ancestors settle into such a consistent arrangement of two pairs of appendages?

It's because we have a belly say theoretical biologists (yes, that's a real thing) at the University of Vienna and the Konrad Lorenz Institute for Evolution and Cognition Research.

Numerous ideas have been proposed to explain different aspects of the origin of paired appendages in vertebrates known as gnathostomes, which includes all living and extinct animals having both a backbone and jaw. "This group does not include the living lampreys and hagfishes, which have neither jaws nor paired fins, although they do have median fins along the midline of the back and tail", says Brian Metscher from the University of Vienna, co-author of the paper in Evolution&Development.

To be acceptable, an explanation must account for not only the fossil evidence, but also for the subtleties of the early development of fins and limbs.

Pairs of appendages situated at front and back ends of the body cavity

"We have drawn together a large body of molecular embryology work, as well as results from paleontology and classical morphology to work out an overall explanation of how the vertebrate embryo forms pairs of appendages along each side, and only two pairs situated at front and back ends of the body cavity," said Laura Nuño de la Rosa, lead author of the study and post-doctoral fellow at the Konrad Lorenz Institute in Altenberg, Austria.




The picture shows lamprey and sturgeon hatchlings as well as a mouse embryo, all imaged with x-ray microtomography. Credit and copyright: Brian Metscher

Embryo segregates into three main layers of tissue

The proposed model incorporates results from much previous research, including information on gene expression and on interactions among the different tissues that make up an early vertebrate embryo. In its earliest stages of development, an embryo segregates into three main layers of tissue: an outer one (ectoderm) that will form the skin and nervous system, an inner layer (endoderm) that becomes the digestive tract, and an in-between layer (mesoderm) that eventually forms muscles, bones, and other organs.

The early mesoderm splits into two layers that line the inside of the body cavity and the outside of the gut.

The new hypothesis proposes that fins or limbs begin to form only at the places where those two layers are sufficiently separated and interact favorably with the ectodermal tissues – namely at the two ends of the forming gut. In between, no fin/limb initiation takes place, because the two mesoderm layers maintain a narrower separation and, the authors propose, interact with the developing gut.

Behind the back end of the digestive tract (the anal opening), along the bottom of the tail, the two mesoderm layers come together as the body wall closes up, forming a single (median) fin. Along the length of the developing gut, the body wall cannot close completely, so the conditions for initiating fins or limbs occur to the left and right of the midline, allowing the development of paired instead of median fins. "You could say that the reason we have four limbs is because we have a belly," adds de la Rosa.

"The most important function of a model like this is to provide a coherent framework for formulating specific hypotheses, which can be tested with molecular and other laboratory methods," says Metscher, who notes that the focus of the hypothesis on global embryonic patterning and tissue interactions emphasizes the importance of accounting for factors other than genes (epigenetics) to understand development and evolution.
