If you want to see Aurora Borealis (the northern lights) in 3-D with your SLR cameras, and even determine the altitude where electrons in the atmosphere emit the light that produces aurora, Ryuho Kataoka from the National Institute of Polar Research in Tokyo, Japan can show you how.
Kataoka came up with an idea for a new method to measure the height of aurora borealis after working on a 3D movie for a planetarium. They used two digital single-lens reflex (SLR) cameras set 8 km apart.
The separation distance between the human eyes is what allows us to see in 3D. When we look at an object, the images captured by the left and right eyes are slightly different from each other and when combined they give the brain the perception of depth. But because the distance between our eyes – about 5 cm – is small, this only works for objects that are not very far away.
Since aurora extend between about 90 and 400 km in altitude, a much larger separation distance is needed to see them in 3D. The researchers used two cameras, mimicking the left and right eyes, separated by 8 km across the Chatanika area in Alaska. Their two digital SLRs, equipped with fisheye lenses and GPS units, captured two simultaneous all-sky images that the researchers combined to create a 3D photograph of the aurora and measure the emission altitude.
"We had initial success when we projected the digital SLR images at a planetarium and showed that the aurora could be seen in 3D. It was very beautiful, and I became confident that it should be possible to calculate the emission altitude using these images," recalls Kataoka, who also works at the Graduate University for Advanced Studies (Sokendai) in Hayama, Japan. He teamed up with other Japanese researchers and an American scientist to do just that. "Using the parallax of the left-eye and the right-eye images, we can calculate the distance to the aurora using a [triangulation] method that is similar to the way the human brain comprehends the distance to an object."
Parallax is the difference in the apparent position of an object when observed at different angles.
Scientists have obtained altitude maps of aurora before. They are useful because they provide information about the energy of the electrons that produce the lights. But this is the first time the emission height of Northern Lights has been measured using images captured with digital SLR cameras. As the authors explain in the new Annales Geophysicae paper, the altitude maps obtained in this way are consistent with previous observations.
The technique is low cost and allows researchers to measure the altitude of small-scale features in the aurora. Further, it opens up the door for citizen scientists to get involved with auroral research.
"Commercially available GPS units for digital SLR cameras have become popular and relatively inexpensive, and it is easy and very useful for photographers to record the accurate time and position in photographic files. I am thinking of developing a website with a submission system to collect many interesting photographs from night-sky photographers over the world via the internet," says Kataoka.
The researchers believe this may lead to new scientific findings, while working to engage the public in auroral research. After all, it was the beauty of 3D imaging of auroras that inspired Kataoka to develop a new tool for scientific research in the first place.
Citation: R. Kataoka, Y. Miyoshi, K. Shigematsu, D. Hampton, Y. Mori, T. Kubo, A. Yamashita, M. Tanaka, T. Takahei, T. Nakai, H. Miyahara, and K. Shiokawa, 'Stereoscopic determination of all-sky altitude map of aurora using two ground-based Nikon DSLR cameras', Ann. Geophys., 31, 1543-1548, 2013 doi:10.5194/angeo-31-1543-2013
