Vincent van Gogh's series of sunflower paintings, while spectacular to fans of his work, have also intrigued scientists because they depict a mutation whose genetic basis was a mystery. In a new study, a team of University of Georgia scientists reveal the mutation behind the distinctive, thick bands of yellow "double flowers" that the post-Impressionist artist painted more than 100 years ago.
The most common sunflower trait is a composite flower head that contains a single whorl of large, flattened, yellow ray florets on the outer perimeter and hundreds to over a thousand individual, tubular, disc florets that can produce seeds. The double-flowered mutants that van Gogh depicted in many of his paintings, on the other hand, have multiple bands of yellow florets and a much smaller proportion of internal disc florets.
To understand the genetic basis of this difference, senior author John Burke, professor of plant biology in the UGA Franklin College of Arts and Sciences, and his colleagues began by using the same plant crossing techniques that Gregor Mendel, a 19th century contemporary of van Gogh, used to lay the foundation of modern genetics. The scientists crossed the common, or "wild type", variety of sunflower with the double-flowered variety, and their initial findings suggested that a single, dominant gene was responsible for creating the double-flowered mutation.
CLICK IMAGE FOR LARGER SIZE. Floral symmetry in sunflower and the similarity of the double-flowered mutant to van Gogh's sunflowers. Entire inflorescences (A, C, E) and individual florets (B, D, F) from wildtype (A, B), double-flowered (C, D) and tubular (E, F) sunflower individuals. Florets are arranged left to right from the inner florets to the outer florets. (G) “Sunflowers (Still Life: Vase with Fifteen Sunflowers)” by Vincent van Gogh (1888) with double-flowered heads pointed out with arrows. Panel G was obtained from Steve Dorrington on flickr (available at http://flic.kr/p/8SsPYb) and is distributed under the terms of the Creative Commons Attribution 2.0 Generic (CC BY 2.0) License. doi:info:doi/10.1371/journal.pgen.1002628.g001
Subsequent crosses of the offspring revealed that a second mutation, which is recessive to both the double-flowered mutation and the wild-type version of the gene, results in a third flower type that is intermediate in form, being elongated and yellow, but tubular and containing the reproductive structures of the interior florets.
The scientists identified the responsible gene and sequenced it to show that in the double-flowered mutation, the portion of the gene that functions as an on/off switch is disrupted, so that the instructions for making the outer rays are turned on in the portions of the plant that would normally produce the internal disc florets. In the second mutation, which results in the tubular florets, the insertion of a "jumping gene" disrupts the ability of the plant to produce normal ray florets. As a result, tubular florets are produced in place of the normal ray florets.
Finally, the scientists screened hundreds of sunflower varieties—wild type, double-flowered and tubular—and found that wild-type sunflower varieties never have a mutation in the HaCYC2c gene, while the double-flowered varieties always have the same mutation in the on/off switch. In addition, the tubular varieties always have a disrupted copy of the gene. "All of this evidence tells us that the mutation we've identified is the same one that van Gogh captured in the 1800s," Burke said.
"In addition to being of interest from a historical perspective, this finding gives us insight into the molecular basis of an economically important trait," he added. "You often see ornamental varieties similar to the ones van Gogh painted growing in people's gardens or used for cut flowers, and there is a major market for them."
Citation: Chapman MA, Tang S, Draeger D, Nambeesan S, Shaffer H, et al. (2012) 'Genetic Analysis of Floral Symmetry in Van Gogh's Sunflowers Reveals Independent Recruitment of CYCLOIDEA Genes in the Asteraceae', PLoS Genet 8(3): e1002628. doi:10.1371/journal.pgen.1002628
