Tiny crystals of zircon, a mineral found in the igneous rock rhyolites, from the Snake River Plain in the Yellowstone hotspot has solidified evidence for a new way of looking at the life cycle of super-volcanic eruptions.

The pattern emerging from new and previous research completed in the last five years is that another super-eruption from the still-alive Yellowstone volcanic field is less likely for the next few million years than previously thought. The last eruption 640,000 years ago created the Yellowstone Caldera and the Lava Creek Tuff in what is now Yellowstone National Park.

The Yellowstone hotspot creates a conveyor belt style of volcanism because of the southwest migration of the North American plate at 2-4 centimeters (about .8 to 1.6 inches) annually over the last 16 million years of volcanism. Due to the movement of the North American plate, the plume interaction with the crust leaves footprints in the form of caldera clusters, in what is now the Snake River Plain.

University of Oregon geologist Ilya Bindeman, left, with lead author and graduate student Dana Drew, working in Bindeman's stable isotope laboratory say that the composition of zircon bits in igneous rocks in the Yellowstone hotspot track tell a new story on how super volcanoes recycle magma. Credit: University of Oregon

 The Picabo volcanic field of southern Idaho, described in a new paper by a six-member team, was active between 10.4 and 6.6 million years ago and experienced at least three, and maybe as many as six, violent caldera-forming eruptions. The field has been difficult to assess, said lead author Dana Drew, a University of Oregon graduate student, because the calderas have been buried by as much as two kilometers of basalt since its eruption cycle died.

 The team theorized that basalt from the mantle plume, rocks from Earth's crust and previously erupted volcanoes are melted together to form the rhyolites erupted in the Snake River Plain. Before each eruption, rhyolite magma is stored in dispersed pockets throughout the upper crust, which are later mixed together, according to geochemical evidence. "We think that this batch-assembly process is an important part of caldera-forming eruptions, and generating rhyolites in general," said Drew.

In reaching their conclusions, Drew and colleagues analyzed radiogenic and stable isotopic data -- specifically oxygen and hafnium -- in zircons detected in rhyolites found at the margins of the Picabo field and from a deep borehole. That data, in combination with whole rock geochemistry and zircon uranium-lead geochronology helped provide a framework to understand the region's ancient volcanic past.

Previous research on the related Heise volcanic field east of Picabo yielded similar results. "There is a growing database of the geochemistry of rhyolites in the Yellowstone hotspot track," Drew said. "Adding Picabo provides a missing link in the database.

Drew and colleagues, through their oxygen isotope analyses, identified a wide diversity of oxygen ratios occurring in erupted zircons near the end of the Picabo volcanic cycle. Such oxygen ratios are referred to as delta-O-18 signatures based on oxygen 18 levels relative to seawater. (Oxygen 18 contains eight protons and 10 neutrons; Oxygen 16, with eight protons and eight neutrons, is the most commonly found form of oxygen in nature)

The approach provided a glimpse into the connection of surface and subsurface processes at a caldera cluster. The interaction of erupted rhyolite with groundwater and surface water causes hydrothermal alteration and the change in oxygen isotopes, thereby providing a fingerprinting tool for the level of hydrothermal alteration, Drew said.

"Through the eruptive sequence, we begin to generate lower delta-O-18 signatures of the magmas and, with that, we also see a more diverse signature," Drew said. "By the time of the final eruption there is up to five per mil diversity in the signature recorded in the zircons." The team attributes these signatures to the mixing of diverse magma batches dispersed in the upper crust, which were formed by melting variably hydrothermally altered rocks -- thus diverse delta-O-18 -- after repeated formation of calderas and regional extension or stretching of the crust.

When the pockets of melt are rapidly assembled, the process could be the trigger for caldera forming eruptions, said University of Oregon geologist Ilya N. Bindeman. "That leads to a homogenized magma, but in a way that preserves these zircons of different signatures from the individual pockets of melt," he said. This research, he added, highlights the importance of using new micro-analytical isotopic techniques to relate geochemistry at the crystal-scale to processes occurring at the crustal-wide scale in generating and predicting large-volume rhyolitic eruptions.

Citation: Dana L. Drew, Ilya N. Bindeman, Kathryn E. Watts, Axel K. Schmitt, Bin Fu, Michael McCurry, 'Crustal-scale recycling in caldera complexes and rift zones along the Yellowstone hotspot track: O and Hf isotopic evidence in diverse zircons from voluminous rhyolites of the Picabo volcanic field, Idaho,' Earth and Planetary Science Letters Volume 381, 1 November 2013, Pages 63–77 DOI: 10.1016/j.epsl.2013.08.007
